Belt Feeder
- Condition: New;
Usage: Coal;
After-sales Service Provided: Engineers available to service overseas;
warranty: 1 year;
Measuring Accuracy: ± 0.5%
Delivery Capacity: 1 ~ 1000 t / h
Belt Width500 ~ 1400 mm
Feeding Distance>= 1500 mm
Speed Range: 0.01 ~ 1.5 m / s
Power Range: 0.37 ~ 10 KW
Belt Feeder
Features:
Weigh Belt
feeder has reliable electronic weighing device;
Can be
equipped with FB-DACS2000 control system, SPL-F microcomputer proportion
centralized-control system or PLC control system.
Unique
deviation-resisting technique can ensure the belt operate well;
Belt of
different width, thickness can be chosen according to specific process
requirements;
Unique
spillage-proof,belt tighting, corrective and scraping device;Sophisticated
weighing system, no operationg friction and with little maintenance;
The
installation of load transducer is treated specially to ensure long-term
operation;
High accuracy speed measuring device is the
effective guarantee for system measurement;
Unique
electrical automatic calibration, chain code calibration, and built-in-weights
calibration;Can choose star-shaped, disc type pre-feeding device for achieving
even feeding;
Can be
equipped with material blockage alarm to make you find blockage in time and
remove them as soon as possible.According to actual conditions
Can, different
hopper and shiled can be chosen to achieve dust-proof, material cut-off and
protective effect.
Can achieve open-loop and close-loop controlOpen, partial open, full closed shell can be chosen.
Specifications:
|
Measuring Accuracy |
± 0.5% |
|
Delivery Capacity |
1 ~ 1000 t / h |
|
Belt Width |
500 ~ 1400 mm |
|
Feeding Distance |
>= 1500 mm |
|
Speed Range |
0.01 ~ 1.5 m / s |
|
Power Range |
0.37 ~ 10 KW |
Special requirements can be designed.
